setup the best light system matrix server with Telegraf + InfluxDB + Grafana

Setup Telegraf on every server you want to collect system matrix from then connect to the central server having InfluxDB, then connect with Grafana to view.

setup the best light system matrix server with Telegraf + InfluxDB + Grafana

🖥️ 1. Central Server Setup (InfluxDB + Grafana)

CODE
sudo apt update
sudo apt install influxdb influxdb-client -y
sudo systemctl enable influxdb
sudo systemctl start influxdb

Check status:

CODE
systemctl status influxdb

Create Database for Metrics

CODE
influx
CREATE DATABASE telegraf
CREATE USER telegraf WITH PASSWORD 'yourpassword'
GRANT ALL ON telegraf TO telegraf
EXIT

Install Grafana

CODE
sudo apt-get install -y apt-transport-https software-properties-common
sudo mkdir -p /etc/apt/keyrings/
wget -q -O - https://packages.grafana.com/gpg.key | sudo gpg --dearmor -o /etc/apt/keyrings/grafana.gpg

echo "deb [signed-by=/etc/apt/keyrings/grafana.gpg] https://packages.grafana.com/oss/deb stable main" | sudo tee /etc/apt/sources.list.d/grafana.list

sudo apt update
sudo apt install grafana -y
sudo systemctl enable grafana-server
sudo systemctl start grafana-server

Access Grafana:
👉 http://your-central-server:3000
(Default login: admin / admin)

*Can setup a domain using caddy

🖥️ 2. Telegraf Setup on Each Server

CODE
sudo apt update
sudo apt install telegraf -y
sudo systemctl enable telegraf

📄 Minimal Telegraf Config (/etc/telegraf/telegraf.conf)

CODE
[agent]
  interval = "10s"
  round_interval = true
  metric_batch_size = 1000
  metric_buffer_limit = 10000
  collection_jitter = "0s"
  flush_interval = "10s"
  flush_jitter = "0s"
  precision = ""
  debug = false
  quiet = false
  logfile = ""

###############################################################################
#OUTPUTS
###############################################################################
[[outputs.influxdb]]
  urls = ["http://YOUR_CENTRAL_SERVER_IP:8086"]
  database = "telegraf"
  username = "telegraf"
  password = "yourpassword"

###############################################################################
#INPUTS
###############################################################################
#CPU metrics
[[inputs.cpu]]
  percpu = true
  totalcpu = true
  collect_cpu_time = false
  report_active = true

#Memory usage
[[inputs.mem]]

#Disk usage
[[inputs.disk]]
  ignore_fs = ["tmpfs", "devtmpfs", "overlay"]

#Network stats
[[inputs.net]]

#System load & uptime
[[inputs.system]]

Save file → Restart Telegraf then Verify logs

CODE
sudo systemctl restart telegraf
sudo journalctl -u telegraf -f

Successfully wrote metrics - should be the output.
